Limit Switches

Technopolymer, Metal, & Explosion Proof
Ordinary & Hazardous Locations



48 Series

Explosion Proof
Built for
Classified Areas

Class I Div 1 (Groups C & D)
Class I Div 2 (Groups A-D)
ATEX Ex d & Ex tb Dust
SIL-2 Capable

45 Series

Rugged Metal
Metal Housing,
IP67 Sealed

Die-Cast Aluminum or 316 SS
Mechanical, Reed, or Inductive
ATEX Ex ia Sensor Options
SIL-2 Capable

40 Series

Quick Set
Tool-Free
Cam Adjustment

IP65 / NEMA 4/4X
Mechanical to 3A @ 250VAC
NAMUR Ex ia Sensor Options
Angled Terminal for Easy Wiring

41 Series

Compact
Non-Metallic,
Corrosion Resistant

Technopolymer Housing & Shaft
Stainless Fasteners
NEMA 4/4X
CSA/UL Listed, CE

Ordinary Location, Electric Actuator Case Studies

6โ€ณ Delta T Ductile Iron Lug Butterfly Valve Tee Assembly w/ MT Series Pneumatic Actuator, Linkage, Limit Switch, & Solenoid Valve 050/051 SeriesCase StudiesLimit SwitchesMT SeriesSolenoid ValvesTee Assembly
September 30, 2026

6โ€ณ Delta T Ductile Iron Lug Butterfly Valve Tee Assembly w/ MT Series Pneumatic Actuator, Linkage, Limit Switch, & Solenoid Valve

Three-Way Flow Control Without the Multiport Ball Valve For larger-diameter piping systems, achieving three-way flow control with a multiport ball valve can quickly become an expensive solution. For this application, Max-Air provided an alternative: a ductile iron tee fitted with two 6" Delta T 051…
Custom Forged Sesto Trunnion Ball Valves w/ Air Controls, Explosion Proof Termination, & Pneumatic Actuators Case StudiesHD SeriesLimit SwitchesMT SeriesSesto ForgedSolenoid Valves
July 28, 2025

Custom Forged Sesto Trunnion Ball Valves w/ Air Controls, Explosion Proof Termination, & Pneumatic Actuators

Even more Pneumatically Automated Explosion Proof Forged Trunnion Valves are shipping today! This order is a great example of the transition point between affordability of a Rack & Pinion and Scotch Yoke. At some point in the consideration of a higher torque actuator, the decision…
3-PC 2000 WOG Ball Valves w/ Extended Butt Weld End Connections Automated w/ Pneumatic & Electric Actuators Case StudiesLimit SwitchesM32 SeriesMA SeriesMT SeriesSolenoid Valves
July 28, 2025

3-PC 2000 WOG Ball Valves w/ Extended Butt Weld End Connections Automated w/ Pneumatic & Electric Actuators

This is a fantastic example of our Extended Butt Weld End Connections available on our Sesto M32 Series 2000 WOG Ball Valves! These are being automated by our Max-Air Rack & Pinion and MA Series Max-Electric Actuators.
Pneumatically Operated Resilient Seated Butterfly Valve w/ Open/Close Feedback & Declutchable Gear Override 050/051 SeriesCase StudiesGOW SeriesLimit SwitchesMT SeriesSolenoid Valves
October 23, 2024

Pneumatically Operated Resilient Seated Butterfly Valve w/ Open/Close Feedback & Declutchable Gear Override

These Delta T Resilient Butterfly Valves in Ductile Iron Wafer Body w/ Stainless Steel Disc & EPDM Seat are being operated by our MT Series Rack & Pinion Actuators. Each assembly has a GOW Series Declutchable Gear Operator for Manual Override. The Solenoid diverts air,…
30″ Delta T Class 150 High Performance Butterfly Valve w/ Spring Return Scotch Yoke Actuator, Limit Switch, Solenoid, Termination, & Tubing 800 SeriesCase StudiesHD SeriesLimit Switches
October 23, 2024

30″ Delta T Class 150 High Performance Butterfly Valve w/ Spring Return Scotch Yoke Actuator, Limit Switch, Solenoid, Termination, & Tubing

This Delta T 851 Series, High Performance, Stainless Steel, Class 150, Butterfly Valves is being automated by our HD Series, Scotch Yoke Actuator and includes limit switch, solenoid valve, and termination. There was also another 18" Valve in the same configuration that shipped with this…
Sesto Class 150 Flange Multiport Ball Valve w/ 3-Way Indicator Limit Switch, Solenoid Valve, & Termination Case StudiesLimit SwitchesMM1F SeriesMT SeriesSolenoid Valves
October 21, 2024

Sesto Class 150 Flange Multiport Ball Valve w/ 3-Way Indicator Limit Switch, Solenoid Valve, & Termination

These Pneumatically Automated Sesto 3-Way Valves include Limit Switch w/ L-Port Beacon, Termination, Solenoid Valve w/ Speed Control Mufflers, and our Patented Dual Travel Stop MT Rack & Pinion Actuator. Each product in this assembly is 100% provided by Max-Air! We have a full line…
Max-Air MT Series Aluminum Rack & Pinion Actuator w/ Gear Operator & Explosion Proof Limit Switch/Termination Case StudiesGOW SeriesLimit SwitchesMT SeriesSolenoid Valves
October 16, 2024

Max-Air MT Series Aluminum Rack & Pinion Actuator w/ Gear Operator & Explosion Proof Limit Switch/Termination

Below you will see an MT Series Rack and Pinion Actuator w/ Explosion Proof Solenoid, Limit Switch Box, and Termination. Our GOW Series Declutchable Override features an easy declutch mechanism, integrated block and bleed capability, and lockout/tagout holes.
